1. Cenário:
2. Especificação:
Type | 2Ports In-1Port Out | ||
---|---|---|---|
Port | Port 1 | Port 2 | |
Operating Frequency (Customized) | 885~890 MHz & 930~935 MHz | 910~915 MHz & 955~960 MHz | |
VSWR | ≤1.22 | ||
Insertion Loss | ≤0.6dB | ≤0.6dB | |
Isolation Between Paths | ≥30dB | ||
PIM3 | ≤-160dBc @2 x 20W | ||
Power Handling | ≤200W | ||
Connector Type | 4.3-10 Female/DIN Female | ||
Aplication | Indoor or Outdoor(IP67) | ||
Impedance | 50Ω | ||
Lightning Protection | 10kA, 10/350μs pulse | ||
Operating Temperature(℃) | -20℃ to + 65℃ | ||
DC/AISG Transparency | By-Pass(Max. 3000mA) | By-Pass(Max. 3000mA) | |
Relative Humidity | 5% ~ 95% | ||
Mounting | Wall or Mast Mount | ||
Weight | ≤3Kg | ||
Packing | 1 PCS/Box |
